CAME AX3024 - 24V irreversible gearmotor for swing gates max 3mt per leaf

3mt irreversible gearmotor for AXO AX3024 24V door (opening time 90 ° adjustable)

When reliability is a principle
Axo is the new electromechanical automation designed to guarantee maximum durability and safety even with large doors. The 2-principle worm screw with its revolutionary technology in fact reduces the wear of the driving bush. The impact forces developed by the movement of the window frame comply with the established standards of the European Standards.

The advantages of Axo
The gearmotor unit, equipped with die-cast aluminum bearing half-shells, is a guarantee of excellent quality and silent operation. Axo is also equipped with adjustable mechanical stops for memorizing the stroke while the 24V version has a simplified connection system with a single three-conductor cable for motor and encoder management.

Full control
The 24V version is combined with the ZLJ24 control panel (ZLJ14 for one door) with encoder technology to guarantee maximum safety for those who use the window.

A design at the service of technology
Came innovation has designed a load-bearing structure that excels for its extreme versatility. The two stems of the versions for doors up to 3 and 7 meters fit harmoniously into a single half-shell group.

Axo is EN TESTED
When maximum comfort, performance and safety are required, Axo 24V technology allows to maximize the automation potential and in particular:

Impact forces under control
Thanks to the tests carried out on a sample frame in the laboratory, the 24 V Axo versions comply with European Standards EN12445 and EN12453 regarding impact forces.

No more blackouts
Axo's 24V control panel automatically recognizes the absence of electricity and activates emergency operation with the auxiliary batteries, to always open and close the gate (option).

Frequent steps
Low voltage gearmotors guarantee operation even in the most severe conditions of use such as in condominium or industrial applications.

Obstacle detection
A special electronic circuit constantly analyzes the presence of any obstacles on the movement of the leaves, operating the eventual stop or the inversion of the motion
